FGP-400 Insight 4-channel HD-SDI Server Player/Recorder

$19,900.00
SKU:
FOR-FGP-400
Need our expert design and installation services?
Contact Us
Design and Installation Services

BIS has an established history of supporting our customers with custom integration to achieve highly functional systems and sub-systems.

FOR-A Insight 4-channel HD-SDI Server Player/Recorder

The FOR-A Insight FGP-400 Production Server is a highly versatile four-channel playout system designed for Studio and OB Van environments. Having wide range of supported wrappers and codecs makes Insight an excellent tool for media contribution and general video playout. The FGP-400 is configured with 4 HD-SDI channels. Optionally, all of them can be configured as a single 4K channel, plus, channels can be teamed for video + alpha output.

Insight has a full web interface that allows users to control the server from any device. User and group levels provide key aspects of the Insight security attributes, which brings confidence to media manipulation. However, a relaxed security mode is also available for a simplified operation for use within trusted environments. Different interface facets allow appropriate information to be exposed to different user roles. System video is streamed to web client instances to show actual content, allowing users to visualize and control Insight from a single computer screen.

Studios and production environments usually have complex interactions between an assorted set of devices, which are coordinated either through human interaction or proprietary links. Insight's flexible event processor can connect to multiple devices and enables interaction with video switchers, routing switchers, CG generators, GPIO connected devices and other studio equipment to orchestrate event triggering for a seamless production.

The Insight FGP-400 Production Server is a tool conceived for evolving infrastructures that require flexible file support, ease of use and event synchronization.

The FOR-A Insight FGP-400 Production Server includes an impressive list of features:

Insight FGP-400 Features

  • 4 HD-SDI channels in a 1RU enclosure. Channels can be configured as input, output or combined video + key.
  • Allows separate resolution playback per channel, i.e., SD, HD, 3G.
  • Redundant power supply
  • Reconfigurable input / output connectors
  • Supports multiple users over a web browser interface. No special software to install or license.
  • Sub-clip editing functionality allows the creation of multiple instances of clips based on in-point and out-point.
  • Files can be ingested and sent to network locations for full workflow integration.
  • Mixed file formats can be included in a single playlist.
  • 4 x 2TB HDD storage in RAID 10 configuration
  • Approximately 150 hours of HD storage @ 50Mbit
  • Supports GPI, VDCP protocols
  • Strong switcher integration. Native connection to FOR-A HVS-series video switchers.
  • Easy and concrete tools for studio requirements
  • Supported Resolutions
    • 4 x HD 1.5/3G channels
      • NTSC - PAL - HD 720p: (23.98/24/25/29.97/30)
      • HD 1080i: (23.98/24/25/29.97/30)
      • HD 1080p: (23.98/24/25/29.97/30) - 4K
    • 4 x SD Channels
      • NTSC
      • PAL
    • 1 x 4K Channel
      • Quad HD 1080p (23.98/24/25/29.97/30)
  • Formats
    • Supported Wrappers
      • MXF
      • MOV
      • AVI
      • MP4
    • Supported Codecs
      • MPEG2
      • H.264
      • XDCAM
      • IMX
      • AVC-Intra
      • DNxHD
  • Channel
    • Configurations
      • Playout x 4
      • Record x 4
      • Video + Key output x 2
      • Or combinations of the above
      • Video + Key requires two outputs per channel
  • Compatibility
    • Device Integration
      • FOR-A Hanabi Switchers
      • BVS/DVS
      • VDCP
  • Output
    • Video + Key Output
      • Play - Play video + key - Record
      • Play Video+Key (Requires 2 outputs per channel)
  • Power Supply
    • Hot Swap Redundant
      • 350W AC power supply w/ PFC 100 VAC ~ 240 VAC, 50/60 Hz, 4.2A ~ 1.8A, UL/CE/FCC listed
  • Dimensions
    • Unit Dimensions (WHD)
      • 17.2" x 1.75" (1RU) x 19.8"
  • Shipping
    • Weight (approx.)
      • 34 lbs.

Please see the "Tech Specs" tab for additional information on the FOR-A Insight 4-channel HD-SDI Server Player/Recorder.

To see more FOR-A products available on the Broadcast Integration Services website, please click or tap here.

Technical Specifications: FOR-A Insight 4-channel HD-SDI Server Player/Recorder

The FOR-A Insight FGP-400 Production Server is a highly versatile four-channel playout system designed for Studio and OB Van environments. Having wide range of supported wrappers and codecs makes Insight an excellent tool for media contribution and general video playout. The FGP-400 is configured with 4 HD-SDI channels. Optionally, all of them can be configured as a single 4K channel, plus, channels can be teamed for video + alpha output.

Insight has a full web interface that allows users to control the server from any device. User and group levels provide key aspects of the Insight security attributes, which brings confidence to media manipulation. However, a relaxed security mode is also available for a simplified operation for use within trusted environments. Different interface facets allow appropriate information to be exposed to different user roles. System video is streamed to web client instances to show actual content, allowing users to visualize and control Insight from a single computer screen.

Studios and production environments usually have complex interactions between an assorted set of devices, which are coordinated either through human interaction or proprietary links. Insight's flexible event processor can connect to multiple devices and enables interaction with video switchers, routing switchers, CG generators, GPIO connected devices and other studio equipment to orchestrate event triggering for a seamless production.

The Insight FGP-400 Production Server is a tool conceived for evolving infrastructures that require flexible file support, ease of use and event synchronization.

The FOR-A Insight FGP-400 Production Server includes an impressive list of features:

Insight FGP-400 Features

  • 4 HD-SDI channels in a 1RU enclosure. Channels can be configured as input, output or combined video + key.
  • Allows separate resolution playback per channel, i.e., SD, HD, 3G.
  • Redundant power supply
  • Reconfigurable input / output connectors
  • Supports multiple users over a web browser interface. No special software to install or license.
  • Sub-clip editing functionality allows the creation of multiple instances of clips based on in-point and out-point.
  • Files can be ingested and sent to network locations for full workflow integration.
  • Mixed file formats can be included in a single playlist.
  • 4 x 2TB HDD storage in RAID 10 configuration
  • Approximately 150 hours of HD storage @ 50Mbit
  • Supports GPI, VDCP protocols
  • Strong switcher integration. Native connection to FOR-A HVS-series video switchers.
  • Easy and concrete tools for studio requirements
  • Supported Resolutions
    • 4 x HD 1.5/3G channels
      • NTSC - PAL - HD 720p: (23.98/24/25/29.97/30)
      • HD 1080i: (23.98/24/25/29.97/30)
      • HD 1080p: (23.98/24/25/29.97/30) - 4K
    • 4 x SD Channels
      • NTSC
      • PAL
    • 1 x 4K Channel
      • Quad HD 1080p (23.98/24/25/29.97/30)
  • Formats
    • Supported Wrappers
      • MXF
      • MOV
      • AVI
      • MP4
    • Supported Codecs
      • MPEG2
      • H.264
      • XDCAM
      • IMX
      • AVC-Intra
      • DNxHD
  • Channel
    • Configurations
      • Playout x 4
      • Record x 4
      • Video + Key output x 2
      • Or combinations of the above
      • Video + Key requires two outputs per channel
  • Compatibility
    • Device Integration
      • FOR-A Hanabi Switchers
      • BVS/DVS
      • VDCP
  • Output
    • Video + Key Output
      • Play - Play video + key - Record
      • Play Video+Key (Requires 2 outputs per channel)
  • Power Supply
    • Hot Swap Redundant
      • 350W AC power supply w/ PFC 100 VAC ~ 240 VAC, 50/60 Hz, 4.2A ~ 1.8A, UL/CE/FCC listed
  • Dimensions
    • Unit Dimensions (WHD)
      • 17.2" x 1.75" (1RU) x 19.8"
  • Shipping
    • Weight (approx.)
      • 34 lbs.

Documentation: FOR-A Insight 4-channel HD-SDI Server Player/Recorder
