RADIO-MICROSERIES Solution Package for Micro Series Audio Mixing

$6,526.00
SKU:
STU-RADIO-MICROSERIES
Need our expert design and installation services?
Contact Us
Design and Installation Services

BIS has an established history of supporting our customers with custom integration to achieve highly functional systems and sub-systems.

Studer Solution Package for Micro Series Audio Mixing

Studer brings together a dynamic "Radio Solution Package", which is based on their Micro Series Audio Mixing System. It gives you everything you need for producing your programming for radio, in-house productions and more! The Studer Micro Core digital audio mixing system is the center point of the package. Connected to the Micro Core are 2 Studer Micro Fader control surfaces, giving you 12 faders, 6 on each controller. The system also includes: 2 JBL LSR308 8" Two-Way Powered Studio Monitors, 2 AKG K240 MKII Professional Studio Headphones and 2 AKG C214 Professional Large-Diaphragm Condenser Microphones. It's everything you need: mixer, faders, mics, speakers and headphones, all at a very attractive price!

The Studer Micro Series is a compact and cost-effective digital audio mixing system that provides the features and functionality of a high-end mixing system. By combining renowned Studer quality with powerful features including AoIP, Lexicon effects processing, VoiceMix automatic mixing and more, the Studer Micro Series delivers unprecedented value for a wide range of applications. The Studer Micro Series is ideal for radio and TV broadcast, production studios, ENG/DSNG and more. With full control from any standard web browser or tablet, the Studer Micro Series provides everything you need for your facility in one box.

At the center of the Studer Micro Series is the Micro Core unit—a rugged 3RU, fanless rack-mountable chassis with integrated I/O, DSP and a control system that’s hosted by an internal web server. Unlike other broadcast solutions that require expensive add-ons, the core features AoIP as standard with eight channels of DANTE I/O.

The core can be controlled using the intuitive GUI via web browser, or with the fader control surface. The powerful feature set and flexible control architecture of the Studer Micro Series is ideally suited for “live-to-air” or “off-air” production environments, as well as remote broadcast, corporate, hospitality sound reinforcement and more. Every function of the core unit can be controlled via the intuitive graphical user interface (GUI). Simply open the web browser on your computer or tablet using LAN or Wi-Fi, enter the IP address of the core, and the GUI appears—no need to install any software. A single device can control multiple core units, and conversely, multiple devices can control a single core simultaneously.

Studer Micro Series Radio Solution Package Features

  • Studer Micro Core Mixing System - compact, integrated form factor (3RU)
  • Two (2) Studer Micro Fader control surfaces - total of twelve (12) faders
  • Two (2) JBL LSR308 8" Two-Way Powered Studio Monitors
  • Two (2) AKG C214 Professional Large-Diaphragm Condenser Microphones
  • Two (2) AKG K240 MKII Professional Studio Headphones
  • The Studer Micro Core processor features:
    • Comprehensive array of I/O, including AoIP (DANTE I/O). See the "Tech Specs" tab for further details.
    • Two stereo Lexicon effects processing engines
    • Integrated stereo Track Player/Recorder
    • Internal Wi-Fi router for connecting with computers and tablets
    • Studer VoiceMix automatic mixing algorithm can mix up to 12 mono inputs
    • Automatic input gain level calibration on each mic input
  • Package Components
    • Studer Micro Core Audio Mixing System
      • 1
    • Studer Micro Fader Control Surfaces - 12 faders total
      • 2
    • JBL LSR308 8" Two-Way Powered Studio Monitors
      • 2
    • AKG C214 Professional Large-Diaphragm Condenser Microphones
      • 2
    • AKG K240 MKII Professional Studio Headphones
      • 2
  • Micro Core Audio I/O
    • HQ Mic Inputs
      • 4
    • Line Inputs
      • 8
    • Line Outputs
      • 12
    • AES Pairs I/O
      • 2 (Input SRC)
    • DANTE I/O
      • 8 (AoIP)
    • Headphone
      • Dedicated DJ and Guest Headphone Out
    • USB Playback & Record
      • 2 (Stereo) Ports
  • Micro Core Input/Output Impedance
    • Mic/Line Inputs
      • 6.8kΩ
    • Line Inputs
      • > 10kΩ
    • Line Outputs
      • 40Ω (electronically balanced)
    • AES/EBU Inputs/Outputs
      • 110Ω
  • JBL LSR308 Speaker
    • Frequency Range
      • 37 Hz - 24 kHz
    • LF Driver Power Amp
      • 56 W Class D
    • HF Driver Power Amp
      • 56 W Class D
    • Input Types
      • 1 x XLR
      • 1 x TRS Balanced
  • AKG C214 Microphone
    • Polar Pattern
      • Cardioid
    • Audio Frequency Bandwidth
      • 20 to 20,000 Hz
    • Audio Output
      • Balanced XLR 3-Pin Male
  • Electrical
    • Micro Core Primary Input Voltage Range
      • 100 to 240 VAC +/- 10%
      • 50/60 Hz
    • Micro Core Power Consumption
      • 100 Watts
    • Micro Core Power Supply
      • Auto-ranging, with Power Factor Correction (PFC)
      • EN/UL approved.
    • JBL LSR308 Speakers
      • 100 to 240 VAC +/- 10%
      • 50/60 Hz
  • Physical (WHD)
    • Micro Core frame
      • 19" x 5.22" (3RU) x 7.77"
    • JBL LSR308 Speaker
      • 10" x 16.5" x 12.1"
  • Shipping
    • Weight
      • 85 lbs. (approx. total for all components)

Please see the "Tech Specs" tab for additional information on the Studer Solution Package for Micro Series Audio Mixing.

To see more Studer products available on the Broadcast Integration Services website, please click or tap here.

Technical Specifications: Studer Solution Package for Micro Series Audio Mixing

Studer brings together a dynamic "Radio Solution Package", which is based on their Micro Series Audio Mixing System. It gives you everything you need for producing your programming for radio, in-house productions and more! The Studer Micro Core digital audio mixing system is the center point of the package. Connected to the Micro Core are 2 Studer Micro Fader control surfaces, giving you 12 faders, 6 on each controller. The system also includes: 2 JBL LSR308 8" Two-Way Powered Studio Monitors, 2 AKG K240 MKII Professional Studio Headphones and 2 AKG C214 Professional Large-Diaphragm Condenser Microphones. It's everything you need: mixer, faders, mics, speakers and headphones, all at a very attractive price!

The Studer Micro Series is a compact and cost-effective digital audio mixing system that provides the features and functionality of a high-end mixing system. By combining renowned Studer quality with powerful features including AoIP, Lexicon effects processing, VoiceMix automatic mixing and more, the Studer Micro Series delivers unprecedented value for a wide range of applications. The Studer Micro Series is ideal for radio and TV broadcast, production studios, ENG/DSNG and more. With full control from any standard web browser or tablet, the Studer Micro Series provides everything you need for your facility in one box.

At the center of the Studer Micro Series is the Micro Core unit—a rugged 3RU, fanless rack-mountable chassis with integrated I/O, DSP and a control system that’s hosted by an internal web server. Unlike other broadcast solutions that require expensive add-ons, the core features AoIP as standard with eight channels of DANTE I/O.

The core can be controlled using the intuitive GUI via web browser, or with the fader control surface. The powerful feature set and flexible control architecture of the Studer Micro Series is ideally suited for “live-to-air” or “off-air” production environments, as well as remote broadcast, corporate, hospitality sound reinforcement and more. Every function of the core unit can be controlled via the intuitive graphical user interface (GUI). Simply open the web browser on your computer or tablet using LAN or Wi-Fi, enter the IP address of the core, and the GUI appears—no need to install any software. A single device can control multiple core units, and conversely, multiple devices can control a single core simultaneously.

Studer Micro Series Radio Solution Package Features

  • Studer Micro Core Mixing System - compact, integrated form factor (3RU)
  • Two (2) Studer Micro Fader control surfaces - total of twelve (12) faders
  • Two (2) JBL LSR308 8" Two-Way Powered Studio Monitors
  • Two (2) AKG C214 Professional Large-Diaphragm Condenser Microphones
  • Two (2) AKG K240 MKII Professional Studio Headphones
  • The Studer Micro Core processor features:
    • Comprehensive array of I/O, including AoIP (DANTE I/O). See the "Tech Specs" tab for further details.
    • Two stereo Lexicon effects processing engines
    • Integrated stereo Track Player/Recorder
    • Internal Wi-Fi router for connecting with computers and tablets
    • Studer VoiceMix automatic mixing algorithm can mix up to 12 mono inputs
    • Automatic input gain level calibration on each mic input
  • Package Components
    • Studer Micro Core Audio Mixing System
      • 1
    • Studer Micro Fader Control Surfaces - 12 faders total
      • 2
    • JBL LSR308 8" Two-Way Powered Studio Monitors
      • 2
    • AKG C214 Professional Large-Diaphragm Condenser Microphones
      • 2
    • AKG K240 MKII Professional Studio Headphones
      • 2
  • Micro Core Audio I/O
    • HQ Mic Inputs
      • 4
    • Line Inputs
      • 8
    • Line Outputs
      • 12
    • AES Pairs I/O
      • 2 (Input SRC)
    • DANTE I/O
      • 8 (AoIP)
    • Headphone
      • Dedicated DJ and Guest Headphone Out
    • USB Playback & Record
      • 2 (Stereo) Ports
  • Micro Core Input/Output Impedance
    • Mic/Line Inputs
      • 6.8kΩ
    • Line Inputs
      • > 10kΩ
    • Line Outputs
      • 40Ω (electronically balanced)
    • AES/EBU Inputs/Outputs
      • 110Ω
  • JBL LSR308 Speaker
    • Frequency Range
      • 37 Hz - 24 kHz
    • LF Driver Power Amp
      • 56 W Class D
    • HF Driver Power Amp
      • 56 W Class D
    • Input Types
      • 1 x XLR
      • 1 x TRS Balanced
  • AKG C214 Microphone
    • Polar Pattern
      • Cardioid
    • Audio Frequency Bandwidth
      • 20 to 20,000 Hz
    • Audio Output
      • Balanced XLR 3-Pin Male
  • Electrical
    • Micro Core Primary Input Voltage Range
      • 100 to 240 VAC +/- 10%
      • 50/60 Hz
    • Micro Core Power Consumption
      • 100 Watts
    • Micro Core Power Supply
      • Auto-ranging, with Power Factor Correction (PFC)
      • EN/UL approved.
    • JBL LSR308 Speakers
      • 100 to 240 VAC +/- 10%
      • 50/60 Hz
  • Physical (WHD)
    • Micro Core frame
      • 19" x 5.22" (3RU) x 7.77"
    • JBL LSR308 Speaker
      • 10" x 16.5" x 12.1"
  • Shipping
    • Weight
      • 85 lbs. (approx. total for all components)

Documentation: Studer Solution Package for Micro Series Audio Mixing
