Grass Valley Single Rear Panel 1x4 Operating Mode for HDA-1941
The Grass Valley HDA-194N-SRP is a single rear connector panel designed to accommodate the HDA-1941 digital video distribution amp. It fits in the Densité 2 frame and provides 1 3G/HD/SD input and 4 3G/HD/SD outputs.
HDA-194N-SRP Features
- Utilize in the Densité 2 frame
- Single rear connector panel
- Use with HDA-1941 Single Channel 3G/HD/SD SDI Video Distribution Amplifier (DA)
- 1 3G/HD/SD input
- 4 3G/HD/SD outputs
- Electrical Inputs (1)
- Signal
- SMPTE ST 259M-C (270 Mb/s)
- SMPTE ST 292M (1.485, 1.485/ 1.001 Gb/s)
- SMPTE ST 424M (2.970, 2.970/ 1.001 Gb/s)
- EN50 83-9 DVI-ASI (270 Mb/s)
- Return loss
- >15 dB up to 1.5 GHz
- >10 dB from 1.5 GHz to 3 GHz
- Electrical Outputs (4)
- Signal
- SMPTE ST 259M-C (270 Mb/s)
- SMPTE ST 292M (1.485, 1.485/ 1.001 Gb/s)
- SMPTE ST 424M (2.970, 2.970/ 1.001 Gb/s)
- EN50 83-9 DVI-ASI (270 Mb/s, all outputs)
- Return loss
- >15 dB up to 1.5 GHz
- >10 dB from 1.5 GHz to 3 GHz
- Jitter (wideband)
- <0.2 UI p-p
- Rise/fall time (Reclocker on)
- <135 ps, 20% to 80%, for HD and 3G
- 400 – 800 ps, 20% to 80%, for SD
- Rise/fall time (Reclocker off)
- <135 ps for all formats (3G, HD, SD)
Please see the "Tech Specs" tab for additional information on the Grass Valley Single Rear Panel 1x4 Operating Mode for HDA-1941.
To see more Grass Valley products available on the Broadcast Integration Services website, please click or tap here.
Technical Specifications: Grass Valley Single Rear Panel 1x4 Operating Mode for HDA-1941
The Grass Valley HDA-194N-SRP is a single rear connector panel designed to accommodate the HDA-1941 digital video distribution amp. It fits in the Densité 2 frame and provides 1 3G/HD/SD input and 4 3G/HD/SD outputs.
HDA-194N-SRP Features
- Utilize in the Densité 2 frame
- Single rear connector panel
- Use with HDA-1941 Single Channel 3G/HD/SD SDI Video Distribution Amplifier (DA)
- 1 3G/HD/SD input
- 4 3G/HD/SD outputs
- Electrical Inputs (1)
- Signal
- SMPTE ST 259M-C (270 Mb/s)
- SMPTE ST 292M (1.485, 1.485/ 1.001 Gb/s)
- SMPTE ST 424M (2.970, 2.970/ 1.001 Gb/s)
- EN50 83-9 DVI-ASI (270 Mb/s)
- Return loss
- >15 dB up to 1.5 GHz
- >10 dB from 1.5 GHz to 3 GHz
- Electrical Outputs (4)
- Signal
- SMPTE ST 259M-C (270 Mb/s)
- SMPTE ST 292M (1.485, 1.485/ 1.001 Gb/s)
- SMPTE ST 424M (2.970, 2.970/ 1.001 Gb/s)
- EN50 83-9 DVI-ASI (270 Mb/s, all outputs)
- Return loss
- >15 dB up to 1.5 GHz
- >10 dB from 1.5 GHz to 3 GHz
- Jitter (wideband)
- <0.2 UI p-p
- Rise/fall time (Reclocker on)
- <135 ps, 20% to 80%, for HD and 3G
- 400 – 800 ps, 20% to 80%, for SD
- Rise/fall time (Reclocker off)
- <135 ps for all formats (3G, HD, SD)
