HDA-395N-3SRP-D Single Rear Conn Panel for Dual 1x5 Operating Mode with DIN Connectors for HDA-3951

$145.00
SKU:
GVG-HDA-395N-3SRP-D
Need our expert design and installation services?
Contact Us
Design and Installation Services

BIS has an established history of supporting our customers with custom integration to achieve highly functional systems and sub-systems.

Grass Valley Single Rear Conn Panel for Dual 1x5 Operating Mode with DIN Connectors for HDA-3951

The Grass Valley HDA-395N-3SRP-D is a single rear connector panel designed to accommodate the HDA-3951 digital video distribution amp. It fits in the Densité 3 frame and provides 2 Dual channel 3G/HD/SD inputs (DIN connectors) and 10 3G/HD/SD outputs, 5 for each channel (DIN connectors).

HDA-395N-3SRP-D Features

  • Utilize in the Densité 3 frame
  • Single rear connector panel
  • Use with HDA-3951 Dual Channel 3G/HD/SD SDI Video Distribution Amplifier (DA)
  • 2 Dual channel 3G/HD/SD inputs (DIN connectors)
  • 10 3G/HD/SD outputs, 5 for each channel (DIN connectors)
  • Electrical Inputs (2 - DIN Connectors)
    • Signal
      • SMPTE ST 259M-C (270 Mb/s)
      • SMPTE ST 292M (1.485, 1.485/ 1.001 Gb/s)
      • SMPTE ST 424M (2.970, 2.970/ 1.001 Gb/s)
      • EN50 83-9 DVI-ASI (270 Mb/s)
    • Return loss
      • >15 dB up to 1.5 GHz
      • >10 dB from 1.5 GHz to 3 GHz
  • Electrical Outputs (10 total - 5 per each input - DIN Connectors)
    • Signal
      • SMPTE ST 259M-C (270 Mb/s)
      • SMPTE ST 292M (1.485, 1.485/ 1.001 Gb/s)
      • SMPTE ST 424M (2.970, 2.970/ 1.001 Gb/s)
      • EN50 83-9 DVI-ASI (270 Mb/s, all outputs)
    • Return loss
      • >15 dB up to 1.5 GHz
      • >10 dB from 1.5 GHz to 3 GHz
    • Jitter (wideband)
      • <0.2 UI p-p
    • Rise/fall time (Reclocker on)
      • <135 ps, 20% to 80%, for HD and 3G
      • 400 – 800 ps, 20% to 80%, for SD
    • Rise/fall time (Reclocker off)
      • <135 ps for all formats (3G, HD, SD)

Please see the "Tech Specs" tab for additional information on the Grass Valley Single Rear Conn Panel for Dual 1x5 Operating Mode with DIN Connectors for HDA-3951.
