AJA 2-Channel Single Mode LC Fiber to 12G-SDI Receiver

FiDO-2R-12G offers unmatched flexibility and cost efficiency for 12G/3G/HD/SD-SDI Fiber conversion, allowing for cable runs up to 10 km (32,808 ft) over standard single-mode fiber optic cable.

FiDO converters use a compact, low-profile enclosure that works well in tight spaces around and behind equipment racks, trucks and on camera.

12G-SDI from Camera to Fiber, Edit and More

Explore how AJA’s latest 12G-SDI solutions can simplify production and post workflows, providing ample bandwidth to handle high resolution, high frame rate and deep color content over a single cable.

Learn more about the FiDO 12G-SDI/optical fiber Mini-Converters,12GDA distribution amplifier, 12GM Muxer/DeMuxer, FS-HDR converter/frame synchronizer and Io 4K Plus Thunderbolt™ 3-equipped audio and video I/O device with 12G-SDI support.

Features

• 2-Channel Single-Mode LC Fiber to 12G-SDI Receiver
• 2 simplex or 1 duplex connection (LC connector)
• 2 independent channels of 12G-SDI output, which also support 6G/3G/HD/SD-SDI
• Both Fiber-to-SDI paths are completely independent
• Uses 5-20VDC power (DWP-U-R1 universal power supply included)
• Five year warranty

• Universal Power Supply
• All AJA Mini-Converters ship with a universal power supply that includes international plug connections for use around the world.
• Compact and Portable
• AJA Mini-Converters are small enough to fit behind a monitor, in the back of a rack or directly on a camera rig. A locking power connector can't accidentally pull loose and an optional P-TAP power cable allows for battery power in remote locations.
• AJA Quality - Guaranteed
• All AJA Mini-Converters are covered by a five year warranty and AJA's advanced replacement policy. If a replacement is necessary, AJA will ship a new unit immediately without the need to send the original unit back first, ensuring you are up and running again as quickly as possible.
• AJA Mini-Matrix
• Information on the complete line of AJA Mini-Converters is now available as a mobile app on iOS. The Mini-Converter product line is extensive and this app helps you find the right converter for any situation, wherever you are.
• Individual products have links back to the main AJA website for more details and you can email product information directly from the app. The free AJA Mini-Matrix app for iPad® and iPhone® is available now in the Apple iTunes® Store.

Please see the "Tech Specs" tab for additional information on the AJA 2-Channel Single Mode LC Fiber to 12G-SDI Receiver.
